  • Easy Load Tap-N-GO Trimmer Head WB-1216

EASY LOAD TAP-N-GO TRIMMER HEAD WB-1216

  • Product Name: Trimmer Head/Brushcutter Head

  • Model No.: WB-1216

  • Head Diameter:  Ø120mm

  • Matched Trimmer Line: Ø2.40mm/Ø0.095″ recommended or other standard trimmer lines

  • Cord Feed: Semic-automatic(Tap-N-Go)

  • Matched Brushcutter: fit the most brushcutters on the market

Ask for Quote

Grass-2HIGHLIGHTS

  • Easy line refilling without disassembling any part of the trimmer head to save your time

STEP 1

WB-1216 STEP1-1

Insert line from one eyelet to opposite one

STEP 2

WB-1216 STEP2-1

Turn the knob to easily load the nylon line

STEP 3

Pull the trimmer line on both ends

  • Heavy duty metal knob, strong and bumps resistant, longer lifetime

  • Aluminum retainers , to prevent the line from breakage during the work

Aluminum Retainer WB1216-1
  • Adaptor bolts available to fit most brands and models

  • Easy to open the head by pushing buttons for maintenance and cleaning

Grass-2Drawing & Spare Parts

WB-1216 Drawing-1

1

5090121

Spool LH

2

5090122

Core

3

5090123

Housing

4

5090124

Eyelet

5

5090125

Spring

6

5090126

Bushing 8mm×1.25LH

6a

5090127

Bushing 10mm×1.0LH

6b

5090128

Bushing 10mm×1.25LH

7

5090129

Cover

8

5090130

Stud 7mm×1.0LH

8a

5090131

Stud 8mm×1.25LH

8b

5090132

Stud 10mm×1.25LH

9

5090133

Spacer Ø8mm

9a

5090134

Spacer Ø10mm
