  • Easy Load Tap-N-Go Trimmer Head WB-1237

EASY LOAD TAP-N-GO TRIMMER HEAD WB-1237

  • Product Name: Trimmer Head/Brushcutter Head

  • Model No.: WB-1237

  • Head Diameter:  Ø130mm/Ø5.12″

  • Matched Trimmer Line: Ø2.40mm/Ø0.095″ recommended or other standard trimmer lines

  • Cord Feed: Semic-automatic(Tap-N-Go)

  • Matched Trimmer/Brushcutter: fits the most trimmers & brushcutters on the market

Ask for Quote

Grass-2HIGHLIGHTS

  • Easy line refilling without disassembling any part of the trimmer head to save your time

STEP 1

Easy Load Tap-N-Go Trimmer Head WB-1237 P1

Insert line from one eyelet to opposite one

STEP 2

Easy Load Tap-N-Go Trimmer Head WB-1237 P2

Turn the knob to easily load the nylon line

STEP 3

Easy Load Tap-N-Go Trimmer Head WB-1237 P3

Pull the trimmer line on both ends

  • The trimmer line is fed by tapping the cutting head on the ground.

  • Heavy duty aluminum knob, strong and bumps resistant, longer lifetime

Easy Load Tap-N-Go Trimmer Head WB-1237 Knob
  • Double line, for cutting and thinning

  • Adaptor bolts available to fit most trimmers and brushcutters

Grass-2Drawing & Spare Parts

Easy Load Tap-N-Go Trimmer Head WB-1237 Drawing

1

50719058

Housing

2

50719059

Line retainer

3

50719060

Adaptor M 8×1.25 Left Male (fits EMAK only)

3

50719061

Adaptor M 8×1.25 Left Female

3

50719062

Adaptor M 8×1.25 Left Male

3

50719063

Adaptor M 10×1.00 Left Female (fits ST only)

3

50719064

Adaptor M 10×1.25 Left Female

3

50719065

Adaptor M 10×1.25 Left Female (fits HU Only)

3

50719066

Adaptor M 10×1.25 Left Male

3

50719067

Adaptor M 10×1.50 Left Female (fits HU only)

3

50719068

Adaptor M 12×1.50 Left Female

3

50719069

Adaptor M 12×1.75 Left Female (fits HU Only)

3

50719070

Adaptor M 14×1.50 Left Female (fits ST only)

4

50719071

Spring

5

50719072

Spool without Line

6

50719073

Upper Cover
